Sultan 25.300
Blaupunkt Ideal,: Sultan 25.300 [Radio] ID = 83343 765x443
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934) | ||||
|---|---|---|---|---|---|
Brand |
Rotstern | ||||
| Year: 1965/1966 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 5: ECC85 ECH81 EAF801 ECL86 EM87 | ||||
| Semiconductors (the count is only for transistors) | AA113 AA113 B250C100 |
| Main principle | Superheterodyne (common); ZF/IF 460 or 452/10700 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) 11 FM circuit(s) |
| Wave bands | Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110; 127; 220; 240 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical |
| Power out | 3 W (unknown quality) |
| from Radiomuseum.org | Model: Sultan 25.300 - Blaupunkt Ideal, Berlin, |
| Material | Wooden case |
| Shape | Tablemodel with Push Buttons. |
| Dimensions (WHD) | 570 x 200 x 195 mm / 22.4 x 7.9 x 7.7 inch |
| Notes | KW: 16,5...42,86 m und gespreiztes 49-m-Band; KW-Lupe. |
| Net weight (2.2 lb = 1 kg) | 7 kg / 15 lb 6.7 oz (15.419 lb) |
| Price in first year of sale | 315.00 DM |
| External source of data | erb |
| Source of data | Handbuch VDRG 1965/1966 |
| Literature/Schematics (1) | -- Original-techn. papers. |
