UHF Einbausatz 07042

Blaupunkt (Ideal), Berlin, später Hildesheim

Data
Forum
Pictures
Collections

  • Year
  • 1960/1961
  • Category
  • Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
  • Radiomuseum.org ID
  • 266056
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 2
  • Main principle
  • Superhet with RF-stage; ZF/IF 38900 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Powered by external power supply or a main unit. / 7,6 & 200 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: UHF Einbausatz 07042 - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Notes

  • Empfangsbereich:
    UHF 470 - 790 MHz (Band IV/V Kanal 14 bis 53 bzw. 21 bis 60 nach neuer Norm)

    UHF Einbausatz für Fernsehgeräte der Saison 1960/61 ohne UHF Tuner:

    - Toskana de Luxe 70300
    - Toledo de Luxe 70340
    - Manila 70640

  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Richard Winter. See "Data change" for further contributors.
