Amplifier DX 18

Amplifier DX 18; Bogen, David Co., (ID = 1810826) Ampl/Mixer Amplifier DX 18; Bogen, David Co., (ID = 1810827) Ampl/Mixer
Amplifier DX 18; Bogen, David Co., (ID = 1342189) Ampl/Mixer Amplifier DX 18; Bogen, David Co., (ID = 1342190) Ampl/Mixer
Use red slider bar for more.
Amplifier DX 18; Bogen, David Co., (ID = 1810826) Ampl/Mixer
Bogen, David Co.,: Amplifier DX 18 [Ampl/Mixer] ID = 1810826 1200x764
Select picture or schematic to display from thumbnails on the right and click for download.
For model Amplifier DX 18, Bogen, David Co., Inc.; New York (NY):
Scanned from the Radio Retailing February 1939 page 39.

Country:  United States of America (USA)
Manufacturer / Brand:  Bogen, David Co., Inc.; New York (NY)
Year: 1939 Category: Audio Amplifier or -mixer
Valves / Tubes 10: 6T7G 6T7G 6L5G 6L5G 6L5G 6L5G 6C8G 6N6G 6N6G 5X4G
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 50 to 60 Hz, 110 Volt
Loudspeaker - This model requires external speaker(s).
Power out 18 W (unknown quality)
from Radiomuseum.org Model: Amplifier DX 18 - Bogen, David Co., Inc.; New
Material Metal case
Shape Tablemodel, with any shape - general.
Notes

Frequency response: 30 to 12000 Hz,
output impedances: 2 - 4 - 9 - 15 - 500 Ω.
Provided for use with wireless remote control Type WR.

Price in first year of sale 54.98 USD
Mentioned in Radio Shack Catalog (1939, page 67)
Literature/Schematics (1) Radio Retailing (Radio & Television R.) (February 1939 page 39)
