Phono Radio LB7 2 boutons à droite et à gauche
Bonvoisin, L., Mizéry & Bonvoisin; Paris
- Country
- France
- Manufacturer / Brand
- Bonvoisin, L., Mizéry & Bonvoisin; Paris
- Year
- 1936 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 360883
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 24 cm = 9.4 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Phono Radio LB7 [2 boutons à droite et à gauche] - Bonvoisin, L., Mizéry &
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 600 x 950 x 420 mm / 23.6 x 37.4 x 16.5 inch
- Notes
-
Platine tourne disque "Garrad Radiogram Unit", tête à aiguille. Plateau de 30 cm, vitesse de 78 tours/min ajustable, arrêt automatique en fin de lecture.
Lampes à culot 6 broches américain ancien.
Voir aussi Bonvoisin Phono Radio LB7 avec quatre boutons sous le cadran.
- Net weight (2.2 lb = 1 kg)
- 40 kg / 88 lb 1.7 oz (88.106 lb)
- Author
- Model page created by Claude Boulet. See "Data change" for further contributors.
- Other Models
-
Here you find 35 models, 23 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Bonvoisin, L., Mizéry & Bonvoisin; Paris
