Jubilar 38W

Jubilar 38W; Brandt Roland Brandt (ID = 272271) Radio

Jubilar 38W; Brandt Roland Brandt (ID = 272272) Radio

Jubilar 38W; Brandt Roland Brandt (ID = 272274) Radio

Jubilar 38W; Brandt Roland Brandt (ID = 877500) Radio
Jubilar 38W; Brandt Roland Brandt (ID = 2475754) Radio Jubilar 38W; Brandt Roland Brandt (ID = 2475756) Radio
Jubilar 38W; Brandt Roland Brandt (ID = 3421) Radio Jubilar 38W; Brandt Roland Brandt (ID = 3422) Radio
Jubilar 38W; Brandt Roland Brandt (ID = 3423) Radio Jubilar 38W; Brandt Roland Brandt (ID = 23540) Radio
Jubilar 38W; Brandt Roland Brandt (ID = 23541) Radio Jubilar 38W; Brandt Roland Brandt (ID = 1025267) Radio
Jubilar 38W; Brandt Roland Brandt (ID = 1393444) Radio Jubilar 38W; Brandt Roland Brandt (ID = 1940295) Radio
Use red slider bar for more.
Jubilar 38W; Brandt Roland Brandt (ID = 2475754) Radio
Brandt Roland Brandt: Jubilar 38W [Radio] ID = 2475754 1168x876
Select picture or schematic to display from thumbnails on the right and click for download.
For model Jubilar 38W, Brandt (Roland Brandt); Berlin

Country:  Germany
Manufacturer / Brand:  Brandt (Roland Brandt); Berlin
alternative name

Motorfahrzeug-Fabrik
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: AF3 AF7 RES164 AZ1
Main principle TRF with regeneration; 1 Special; 1 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Jubilar 38W - Brandt Roland Brandt; Berlin
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 503 x 270 x 250 mm / 19.8 x 10.6 x 9.8 inch
Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Price in first year of sale 147.00 RM
Source of data Handbuch WDRG 1938 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung


All listed radios etc. from Brandt (Roland Brandt); Berlin
