Ortsempfänger O3 (Q3)
Brandt (Roland Brandt); Berlin
- Country
- Germany
- Manufacturer / Brand
- Brandt (Roland Brandt); Berlin
- Year
- 1927 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 229515
-
- alternative name: Motorfahrzeug-Fabrik
- Number of Tubes
- 3
- Valves / Tubes
- Main principle
- TRF with regeneration
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case, TUBES VISIBLE.
- from Radiomuseum.org
- Model: Ortsempfänger O3 - Brandt Roland Brandt; Berlin
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 198 x 80 x 145 mm / 7.8 x 3.1 x 5.7 inch
- Notes
-
Der Brandt Ortsempfänger O3 (bei Abele Historische Radios Bd. III mit Q3 bezeichnet) ist ein Einkreis 3-Röhren Empfänger mit Widerstandskopplung der NF-Stufen.
2-fach Spulenkoppler, ein gemeinsamer Heizregler.
Siehe auch Brandt 3-Röhren Orts- und Fernempfänger B3 im Bakelitgehäuse (3 Spulen).
- Net weight (2.2 lb = 1 kg)
- 0.8 kg / 1 lb 12.2 oz (1.762 lb)
- Mentioned in
- Historische Radios Band III (p.54)
- Author
- Model page created by Hartmut Völler. See "Data change" for further contributors.
