Atelier P2; Braun; Frankfurt (ID = 2057275) R-Player
Braun; Frankfurt: Atelier P2 [R-Player] ID = 2057275 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Atelier P2, Braun; Frankfurt

Country:  Germany
Manufacturer / Brand:  Braun; Frankfurt
Year: 1982–1986 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 - 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Atelier P2 - Braun; Frankfurt
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 445 x 115 x 360 mm / 17.5 x 4.5 x 14.2 inch
Notes

Direkt angetriebener, halbautomatischer Plattenspieler mit "ULM"  (ultra low mass) Tonarm und Subchassis. Magnetisches Tonabnehmersystem Ortofon MAG 2-E mit elliptischer Nadel.

Zwei Geschwindigkeiten 33 und 45 Upm. Antiskating einstellbar auf konische & elliptische Abtaster.

Daten:

  • eff. Tonarmasse: 11g
  • Auflagekraft nominal: 15 mN
  • Übertragungsbereich: 20 Hz - 20 kHz
  • Ausgangsspannung (1 kHz): 0,8 mV/cm/sec

Anschlußkabel mit Cinch-Steckern und separatem Masseanschluss. Stromversorgung vorbereitet zur internen Umschaltung auf 110 - 120 V.

Ausführung: schwarz, Kompaktguss-Kunststoffgehäuse mit Deckel aus glasklarem Thermoplast.

Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale 798.00 DM
Mentioned in Braun HiFi-Elektronik 1982/ 1983/ 1985/86
