Atelier R1; Braun; Frankfurt (ID = 457692) Radio
Braun; Frankfurt: Atelier R1 [Radio] ID = 457692 900x348
Select picture or schematic to display from thumbnails on the right and click for download.
For model Atelier R1, Braun; Frankfurt

Country:  Germany
Manufacturer / Brand:  Braun; Frankfurt
Year: 1982–1985 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 120; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 80 W (unknown quality)
from Radiomuseum.org Model: Atelier R1 - Braun; Frankfurt
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 445 x 70 x 375 mm / 17.5 x 2.8 x 14.8 inch
Notes

Stereo-Receiver, digitale Frequenzanzeige. 5 frei programmierbare Stationstasten.Im UKW-Bereich sorgen Dual Gate MOS-FET und ein speziell entkoppelter Oszillator dafür, dass schwächere Sender nicht von starken Ortssendern «weggedrückt» werden.

Die Ausgangsleistung beträgt 2x 50W an 4 Ohm bzw. 2x 40W an 8 Ohm (Sinus)

Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)
Price in first year of sale 1'250.00 DM
Source of data - - Data from my own collection

Model page created by Peter Böhm. See "Data change" for further contributors.
