Apex 767C

Apex 767C; Breville; Sydney (ID = 2395568) Radio
Use red slider bar for more.
Apex 767C; Breville; Sydney (ID = 2395568) Radio
Breville; Sydney: Apex 767C [Radio] ID = 2395568 1400x2031
Select picture or schematic to display from thumbnails on the right and click for download.
For model Apex 767C, Breville; Sydney:
The Sun, Sydney, NSW, 20/6/1948, Page 13 (Trove Newspapers).

Country:  Australia
Manufacturer / Brand:  Breville; Sydney
Year: 1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1M5G 1C7G 1M5G 1K7G 1L5G
Main principle Superhet with RF-stage; ZF/IF 252 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
Power out
from Radiomuseum.org Model: Apex 767C - Breville; Sydney
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 29.5 x 33 x 12.5 inch / 749 x 838 x 318 mm
Notes

This model uses a synchronous vibrator power unit.

See also table version, Acme Model 767T.

Price in first year of sale 49.75 AUS £
Circuit diagram reference Australian Official Radio Service Manual Vol. VII
Mentioned in Mingay's "Radio Diagram & I.F. Index
Literature/Schematics (1) Australian Official Radio Service Manual AORSM (Volume 7, 1949, Page 90.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
