Gloucester Cruiser 62

Gloucester Cruiser 62; Breville; Sydney (ID = 2376618) Radio
Use red slider bar for more.
Gloucester Cruiser 62; Breville; Sydney (ID = 2376618) Radio
Breville; Sydney: Gloucester Cruiser 62 [Radio] ID = 2376618 1228x2100
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gloucester Cruiser 62, Breville; Sydney:
From brochure.

Country:  Australia
Manufacturer / Brand:  Breville; Sydney
Year: 1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: AK1 6K7 E444N 6F6 80
Main principle Superheterodyne (common); ZF/IF 446 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Gloucester Cruiser 62 - Breville; Sydney
Material Wooden case
Shape Console with any shape - in general
Notes

See also Chelsea Cruiser with same chassis.

Price in first year of sale 27.00 AUS £
Mentioned in -- Original prospect or advert

Model page created by Martin Kent. See "Data change" for further contributors.



All listed radios etc. from Breville; Sydney
Here you find 452 models, 169 with images and 167 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
