MK 23

MK 23; Budapesti (ID = 760002) R-Player
MK 23; Budapesti (ID = 1917059) R-Player MK 23; Budapesti (ID = 260477) R-Player
MK 23; Budapesti (ID = 448581) R-Player MK 23; Budapesti (ID = 448582) R-Player
MK 23; Budapesti (ID = 448680) R-Player MK 23; Budapesti (ID = 1457786) R-Player
MK 23; Budapesti (ID = 1493710) R-Player MK 23; Budapesti (ID = 1493711) R-Player
MK 23; Budapesti (ID = 1899183) R-Player MK 23; Budapesti (ID = 1933733) R-Player
Use red slider bar for more.
MK 23; Budapesti (ID = 1917059) R-Player
Budapesti: MK 23 [R-Player] ID = 1917059 1400x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model MK 23, Budapesti Rádiótechnikai Gyár (BRG)

Country:  Hungary
Manufacturer / Brand:  Budapesti Rádiótechnikai Gyár (BRG)
Year: 1972 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 10: BC149 BC149 BC149 BC149 AD161 AD162 AC128 AC128 2SC828 2SB324
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220/ 6× 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: MK 23 - Budapesti Rádiótechnikai Gyár
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 307 x 60 x 216 mm / 12.1 x 2.4 x 8.5 inch
Notes Der Monokassettenrecorder MK23 ist der Nachfolger des MK21, jetzt mit eingebautem Netzteil. Der Frequenzgang beträgt 60 Hz bis 10000 Hz, Eingänge für Mikrofon und für Rundfunk.
Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
Price in first year of sale 3'100.00 HUF

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Budapesti Rádiótechnikai Gyár (BRG)
Here you find 80 models, 72 with images and 23 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
