Qualiton HiFi M20

Qualiton HiFi M20; Budapesti (ID = 917163) R-Player

Qualiton HiFi M20; Budapesti (ID = 917164) R-Player

Qualiton HiFi M20; Budapesti (ID = 2099351) R-Player

Qualiton HiFi M20; Budapesti (ID = 2099352) R-Player

Qualiton HiFi M20; Budapesti (ID = 2099353) R-Player

Qualiton HiFi M20; Budapesti (ID = 2099354) R-Player

Qualiton HiFi M20; Budapesti (ID = 2099355) R-Player

Qualiton HiFi M20; Budapesti (ID = 2099356) R-Player

Qualiton HiFi M20; Budapesti (ID = 2099357) R-Player

Qualiton HiFi M20; Budapesti (ID = 2099358) R-Player
Qualiton HiFi M20; Budapesti (ID = 583605) R-Player Qualiton HiFi M20; Budapesti (ID = 583606) R-Player
Qualiton HiFi M20; Budapesti (ID = 985629) R-Player Qualiton HiFi M20; Budapesti (ID = 985631) R-Player
Qualiton HiFi M20; Budapesti (ID = 1487188) R-Player Qualiton HiFi M20; Budapesti (ID = 1487190) R-Player
Qualiton HiFi M20; Budapesti (ID = 1674349) R-Player Qualiton HiFi M20; Budapesti (ID = 1674350) R-Player
Qualiton HiFi M20; Budapesti (ID = 1674351) R-Player Qualiton HiFi M20; Budapesti (ID = 1674352) R-Player
Use red slider bar for more.
Qualiton HiFi M20; Budapesti (ID = 583605) R-Player
Budapesti: Qualiton HiFi M20 [R-Player] ID = 583605 790x664
Select picture or schematic to display from thumbnails on the right and click for download.
For model Qualiton HiFi M20, Budapesti Rádiótechnikai Gyár (BRG):
Thanks for Mr.Herczeg István Veszprém, Hungary!

Country:  Hungary
Manufacturer / Brand:  Budapesti Rádiótechnikai Gyár (BRG)
Year: 1968 Category: Sound/Video Recorder and/or Player
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Qualiton HiFi M20 - Budapesti Rádiótechnikai Gyár
Material Modern plastics (no Bakelite or Catalin)
Dimensions (WHD) 355 x 325 x 165 mm / 14 x 12.8 x 6.5 inch
Notes

Speed: 2,38-4,76-9,53 cm/sec.

Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)
Price in first year of sale 4'200.00 HUF
Source of data -- Collector info (Sammler)
Literature/Schematics (4) Rádiótechnika Évkönyv, 1968.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Budapesti Rádiótechnikai Gyár (BRG)
Here you find 80 models, 72 with images and 23 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
