Qualiton Junior M9

Qualiton Junior M9; Budapesti (ID = 1284253) R-Player

Qualiton Junior M9; Budapesti (ID = 1284251) R-Player

Qualiton Junior M9; Budapesti (ID = 1284329) R-Player
Qualiton Junior M9; Budapesti (ID = 1284260) R-Player Qualiton Junior M9; Budapesti (ID = 447619) R-Player
Qualiton Junior M9; Budapesti (ID = 1284261) R-Player Qualiton Junior M9; Budapesti (ID = 1284262) R-Player
Qualiton Junior M9; Budapesti (ID = 1284264) R-Player Qualiton Junior M9; Budapesti (ID = 1284266) R-Player
Qualiton Junior M9; Budapesti (ID = 1284267) R-Player Qualiton Junior M9; Budapesti (ID = 1284268) R-Player
Qualiton Junior M9; Budapesti (ID = 1284269) R-Player Qualiton Junior M9; Budapesti (ID = 1284270) R-Player
Use red slider bar for more.
Qualiton Junior M9; Budapesti (ID = 1284260) R-Player
Budapesti: Qualiton Junior M9 [R-Player] ID = 1284260 933x741
Select picture or schematic to display from thumbnails on the right and click for download.
For model Qualiton Junior M9, Budapesti Rádiótechnikai Gyár (BRG):
Thanks for Mr.Gömör Géza, Hungary, Budapest and Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation.

Country:  Hungary
Manufacturer / Brand:  Budapesti Rádiótechnikai Gyár (BRG)
Year: 1967 ? Category: Sound/Video Recorder and/or Player
Valves / Tubes 1: EM80
Semiconductors (the count is only for transistors) 7: AC125 AC125 AC126 AC126 AC128 AC128 AC128
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 25.2 cm = 9.9 inch
Power out 0.7 W (unknown quality)
from Radiomuseum.org Model: Qualiton Junior M9 - Budapesti Rádiótechnikai Gyár
Material Various materials
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 360 x 300 x 140 mm / 14.2 x 11.8 x 5.5 inch
Notes Speaker: 80×252 mm, 50 Ohm, 2 W.
Net weight (2.2 lb = 1 kg) 6.5 kg / 14 lb 5.1 oz (14.317 lb)
Price in first year of sale 3'300.00 HUF
Literature/Schematics (1) RÁVILL Árjegyzék, 1967
Literature/Schematics (4) Híradástechnikai cikkek kereskedelmi árjegyzéke, BP. 1967

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
