Portable 241

Burndept Ltd. London

Data
Forum
Pictures
Collections

  • Year
  • 1935 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 248140

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • TRF (Tuned-Radio-Frequency but use of regeneration unknown); 1 AF stage(s)
  • Tuned circuits
  • 2 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Storage and/or dry batteries / 2 & 9 & 120 Volt
  • Loudspeaker
  • Presumably Dynamic Loudspeaker (moving coil)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: Portable 241 - Burndept Ltd. London
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes

  • Suitcase style.

    HT Battery: Vidor 17772 using various taps (Vidor owned Burndept from 1934). GB also various taps See also for comparison Tapped HT Battery  Winner 120 and Tapped  GB Winner 9

    LT 2V Lead Acid Accumulator, leak proof valves or gel type.

    Vidor branded version is CN248.

    May be operated with lid closed.

  • Author
  • Model page created by Michael Watterson. See "Data change" for further contributors.
