DUG43; Bush Radio; London (ID = 1036049) Radio
Select picture or schematic to display from thumbnails on the right and click for download.
Country:  Great Britain (UK)
Manufacturer / Brand:  Bush Radio; London
Year: 1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: TH21C VP13C TDD13C Pen36C C1
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Power type and voltage AC/DC-set / 180-260 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Model: DUG43 - Bush Radio; London
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes Metal rectifier. A similar chassis is fitted in the DAC43 table radio and the RG43 radiograms.
Literature/Schematics (1) Trader sheet 611

Model page created by Howard Craven. See "Data change" for further contributors.
