376 Ch= 395

Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC

Data
Forum
Pictures
Collections

  • Year
  • 1954/1955
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 244795
    • alternative name: CMC Canada || Marconi, Canada

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 117 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
  • Power out
  • 6 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 376 Ch= 395 - Canadian Marconi Co. Ltd. CMC,
  • Shape
  • Console with any shape - in general
  • Notes

  • The Canadian Marconi model 376 is an 8-tube table radio for standard broadcast and 5.8-18.1 MHz shortwave. With automatic record changer. Available in Walnut, Mahogany and Blond Mahogany.
    For 25 or 60 Hz depending on nameplate rating.

    Same schematic and chassis as model 399.

  • Literature/Schematics (3)
  • Marconi Folder Radios..Phono-Combinations..HI-FI for 1955
  • Author
  • Model page created by Ernst Erb. See "Data change" for further contributors.
