6A10

6A10 ; Canadian Marconi Co. (ID = 1193281) R-Player

6A10 ; Canadian Marconi Co. (ID = 1193282) R-Player

6A10 ; Canadian Marconi Co. (ID = 1193283) R-Player

6A10 ; Canadian Marconi Co. (ID = 1193284) R-Player

6A10 ; Canadian Marconi Co. (ID = 1193285) R-Player

6A10 ; Canadian Marconi Co. (ID = 1193286) R-Player

6A10 ; Canadian Marconi Co. (ID = 1193287) R-Player

6A10 ; Canadian Marconi Co. (ID = 1193288) R-Player

6A10 ; Canadian Marconi Co. (ID = 1193289) R-Player

6A10 ; Canadian Marconi Co. (ID = 1193290) R-Player
Use red slider bar for more.
6A10 ; Canadian Marconi Co. (ID = 1193281) R-Player
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Canada
Manufacturer / Brand:  Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
alternative name

CMC Canada || Marconi, Canada
Year: 1947/1948 Category: Sound/Video Recorder and/or Player
Valves / Tubes 6: 6SJ7GT 6J5GT 6SQ7GT 6V6GT 6E5 5Y3GT
Main principle Audio-Amplification
Wave bands - without
Details Recording phonogr.-Disc Recorder
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: 6A10 - Canadian Marconi Co. Ltd. CMC,
Notes The Marconi Model 6A10 is an AC operated 6 Tube combination Disk Recorder with Microphone, Public Address System and phonograph. Uses Qty(1) Elliptical PM 6" x 9" speaker. Built-in record player is not a record changer.
Literature/Schematics (1) Marconi Service Manual Volume No. 2 (Volume 2, Page 293)

Model page created by John Kusching. See "Data change" for further contributors.
