- Country
- Canada
- Manufacturer / Brand
- Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
- Year
- 1937 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 298712
-
- alternative name: CMC Canada || Marconi, Canada
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 462.5 kHz; 3 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Direct Current supply (DC) / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
- Power out
- 1.35 W (2 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 94 - Canadian Marconi Co. Ltd. CMC,
- Notes
-
The Canadian Marconi model 94 is a 6 VDC farm radio with a vibrator power supply for B+. The three wavebands are 530-1640 kHz (Broadcast), 1.62-5.2 MHz, and 5.2-18 MHz (Short Wave).
- Literature/Schematics (1)
- Marconi Service Manual (Volume 1) (Page 159-162)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
