C8M-18805

C8M-18805 ; Canadian Marconi Co. (ID = 1194068) Car Radio

C8M-18805 ; Canadian Marconi Co. (ID = 1194069) Car Radio

C8M-18805 ; Canadian Marconi Co. (ID = 1194070) Car Radio

C8M-18805 ; Canadian Marconi Co. (ID = 1194071) Car Radio

C8M-18805 ; Canadian Marconi Co. (ID = 1194072) Car Radio

C8M-18805 ; Canadian Marconi Co. (ID = 1194073) Car Radio

C8M-18805 ; Canadian Marconi Co. (ID = 1194074) Car Radio

C8M-18805 ; Canadian Marconi Co. (ID = 1194076) Car Radio

C8M-18805 ; Canadian Marconi Co. (ID = 1194077) Car Radio

C8M-18805 ; Canadian Marconi Co. (ID = 1194078) Car Radio
C8M-18805 ; Canadian Marconi Co. (ID = 1194067) Car Radio
Use red slider bar for more.
C8M-18805 ; Canadian Marconi Co. (ID = 1194067) Car Radio
Canadian Marconi Co.: C8M-18805 [Car Radio] ID = 1194067 933x460
Select picture or schematic to display from thumbnails on the right and click for download.
For model C8M-18805, Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC:
Picture from Marconi Radio Service Manual

Country:  Canada
Manufacturer / Brand:  Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
alternative name

CMC Canada || Marconi, Canada
Year: 1946 ?? Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 6: 6SK7GT 6SA7GT 6SK7GT 6SQ7GT 6V6GT 6X5GT
Main principle Superhet with RF-stage; ZF/IF 265 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6.3 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: C8M-18805 - Canadian Marconi Co. Ltd. CMC,
Material Metal case
Shape Chassis only or for «building in»
Notes The Marconi Model C8M-18805 is a 6.3V Battery operated 6 Tube Car Radio. BC Band Tuning Range: 540 to 1610kHz. B+ generated from Vibrator. Uses Qty(1) Elliptical 6" x 9" speaker. Made for Monarch and Mercury. Marconi Model 8A-18805-A uses the same schematic.
Literature/Schematics (1) Marconi Service Manual Volume No. 2 (Volume 2, Page 353)

Model page created by John Kusching. See "Data change" for further contributors.
