402 Ch= 8H1, 4S2
- Manufacturer / Brand
- Canadian Admiral Co. Ltd; Long Branch, Ont.
- 1958 ?
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- Main principle
- Superhet with RF-stage; ZF/IF 455/10700 kHz; 5 AF stage(s)
- Tuned circuits
- 6 AM circuit(s) 8 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117 Volt
- 4 Loudspeakers
- Power out
- 12 W (17 W max.)
- Wooden case
- from Radiomuseum.org
- Model: 402 Ch= 8H1, 4S2 - Canadian Admiral Co. Ltd; Long
- Console, Lowboy (legs < 50 %).
The Canadian Admiral model 402 is a 12-tube AM/FM console radio with built in record changer and tuning eye tube. Contains tuner chassis 8H1 and amplifier chassis 4S2. Has 12 inch woofer, 5.5 inch mid range, 4 inch mid range and 3.5 inch tweeter. Similar to USA model 402.
Model Colour 402 Mahogany 403 Blond 404 Sierra
- Literature/Schematics (1)
- Radio College of Canada (RCC) (Supplement 45)
- Model page created by Tom Seeger. See "Data change" for further contributors.
