B492

B492 ; Canadian (ID = 606110) Radio
Use red slider bar for more.
B492 ; Canadian (ID = 606110) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Canada
Manufacturer / Brand:  Canadian Westinghouse, Hamilton
alternative name

Westinghouse Canada
Year: 1947/1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1A7GT 1N5GT 1H5GT 1Q5GT
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 90 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: B492 - Canadian Westinghouse,
Circuit diagram reference Radio College of Canada
Literature/Schematics (1) Westinghouse page 129

Model page created by Dirk Taekels. See "Data change" for further contributors.
