B541 X

B541 X ; Canadian (ID = 603173) Radio

B541 X ; Canadian (ID = 603174) Radio

B541 X ; Canadian (ID = 603175) Radio
Use red slider bar for more.
B541 X ; Canadian (ID = 603173) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Canada
Manufacturer / Brand:  Canadian Westinghouse, Hamilton
alternative name

Westinghouse Canada
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1C7G 1D5G 1F7G 1H4G 1J6G
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 90 & 2 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: B541 X - Canadian Westinghouse,
Circuit diagram reference Radio College of Canada
Literature/Schematics (1) Westinghouse page 61, 68, 69

Model page created by Dirk Taekels. See "Data change" for further contributors.
