P-405 Ch= 2131

P-405 Ch= 2131; Canadian (ID = 607292) Radio
P-405 Ch= 2131; Canadian (ID = 1293188) Radio P-405 Ch= 2131; Canadian (ID = 1293189) Radio
P-405 Ch= 2131; Canadian (ID = 1293190) Radio P-405 Ch= 2131; Canadian (ID = 1293191) Radio
P-405 Ch= 2131; Canadian (ID = 1293192) Radio P-405 Ch= 2131; Canadian (ID = 1293193) Radio
Use red slider bar for more.
P-405 Ch= 2131; Canadian (ID = 1293188) Radio
Canadian: P-405 Ch= 2131 [Radio] ID = 1293188 933x787
Select picture or schematic to display from thumbnails on the right and click for download.
For model P-405 Ch= 2131, Canadian Westinghouse, Hamilton:
By courtesy of guest Colin Chase, Nova Scotia, Canada
Westinghouse P-405 Front View #1

Country:  Canada
Manufacturer / Brand:  Canadian Westinghouse, Hamilton
alternative name

Westinghouse Canada
Year: 1950/1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1R5 1T4 1U5 3V4
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / AC/DC 117V / 67.5 & 7.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: P-405 Ch= 2131 - Canadian Westinghouse,
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Notes Built in loop antenna.
Circuit diagram reference Radio College of Canada
Literature/Schematics (1) Westinghouse supplement No.22 page 93

Model page created by Dirk Taekels. See "Data change" for further contributors.
