Candle 5 Band All Transistor TK-1848 (Japan 712)

Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 274659) Radio Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 274660) Radio
Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 274661) Radio Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 259520) Radio
Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 545634) Radio Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 624757) Radio
Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 631014) Radio Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 870106) Radio
Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 870107) Radio Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 870108) Radio
Use red slider bar for more.
Candle 5 Band All Transistor TK-1848 ; Tokyo Transistor (ID = 274659) Radio
Tokyo Transistor: Candle 5 Band All Transistor TK-1848 [Radio] ID = 274659 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Candle 5 Band All Transistor TK-1848 (Japan 712), Tokyo Transistor Industry Co., LTD.; Tokyo

Country:  Japan
Manufacturer / Brand:  Tokyo Transistor Industry Co., LTD.; Tokyo
Brand

Candle
Year: 1964 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 18:
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Line / Batteries (any type) / 117 or 220 / D: 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9.5 cm = 3.7 inch
Power out 0.6 W (unknown quality)
from Radiomuseum.org Model: Candle 5 Band All Transistor TK-1848 - Tokyo Transistor Industry Co.,
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 285 x 250 x 105 mm / 11.2 x 9.8 x 4.1 inch
Notes

Candle Solid State 18, 5 Band AC/DC Radio TK-1848;

FM:              86 - 108 MHz,
AM:            530 - 1600 kHz,
SW:               4 - 12 MHz,
MB:             1.6 - 4 MHz,
VHF/PB:    108  - 174 MHz,
AFC button, tone control, dial light, band indicator, 117 or 220 VAC.
Power consumption max. 4.6 W

Material: 4mm cardboard covered with Vinyl.

Made in Japan 712

Net weight (2.2 lb = 1 kg) 3.1 kg / 6 lb 13.3 oz (6.828 lb)
Collectors' prices

Model page created by Peter Hoddow. See "Data change" for further contributors.



All listed radios etc. from Tokyo Transistor Industry Co., LTD.; Tokyo
Here you find 52 models, 46 with images and 3 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
