• Country
• United States of America (USA)

• Manufacturer / Brand
• CBS-Columbia Inc.; New York, NY

• Year
• 1952 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 359977

• • alternative name: CBS Electronics || Columbia Phonographs || Columbia Records

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 21

• Valves / Tubes
• 6BC5 6J6 6CB6 6CB6 6CB6 6AL5 12BH7 6AU6 6AL5 6SQ7 6V6GT 12BH7 12BZ7 12BH7 6AL5 12BH7 6BQ6GT 6W4GT 1AX2 5U4G 17HP4

• Main principle
• Superhet, IF regeneration

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60Hz, 117V=110-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 17M18 Ch= 817, 817-1 - CBS-Columbia Inc.; New York,

• Shape
• Tablemodel, with any shape - general.

• Notes

• CBS-Columbia model 17M18 is a 17” b/w TV with US standard VHF tuner channels 2 thru 13, Equipped with chassis 817, 817-1, VHF tuner T2306 and picture tube 17HP4.



• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 188, folder 5, dated 12-52)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
