Transistor Convertible C610 (?)
CBS-Columbia Inc.; New York, NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- CBS-Columbia Inc.; New York, NY
- Year
- 1960 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 349040
-
- alternative name: CBS Electronics || Columbia Phonographs || Columbia Records
https://www.ebay.com/itm/257680063033
https://www.ebay.com/itm/257680063033
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 1 x 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Transistor Convertible C610 - CBS-Columbia Inc.; New York,
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 115 x 75 x 32 mm / 4.5 x 3 x 1.3 inch
- Notes
-
See also Grundig Micro-Transistor-Boy.
Made in W.Germany by Grundig Radiowerke Fürth
- Net weight (2.2 lb = 1 kg)
- 0.3 kg / 0 lb 10.6 oz (0.661 lb)
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Aldo Andreani. See "Data change" for further contributors.
