JW5

JW5; Centrum-Radio, (ID = 1277602) Radio
JW5; Centrum-Radio, (ID = 283477) Radio JW5; Centrum-Radio, (ID = 283478) Radio
JW5; Centrum-Radio, (ID = 283479) Radio JW5; Centrum-Radio, (ID = 283480) Radio
JW5; Centrum-Radio, (ID = 283481) Radio JW5; Centrum-Radio, (ID = 1132707) Radio
JW5; Centrum-Radio, (ID = 1132708) Radio JW5; Centrum-Radio, (ID = 1132709) Radio
JW5; Centrum-Radio, (ID = 1132710) Radio JW5; Centrum-Radio, (ID = 1132711) Radio
Use red slider bar for more.
JW5; Centrum-Radio, (ID = 283477) Radio
Centrum-Radio,: JW5 [Radio] ID = 283477 536x418
Select picture or schematic to display from thumbnails on the right and click for download.
For model JW5, Centrum-Radio, Gylling & Co.; Stockholm

Country:  Sweden
Manufacturer / Brand:  Centrum-Radio, Gylling & Co.; Stockholm
Brand

Gylling
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A8 6U7G 6Q7 6F6EG 5Y3G
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 115; 130; 150; 210; 225; 245 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: JW5 - Centrum-Radio, Gylling & Co.;
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 430 x 300 x 250 mm / 16.9 x 11.8 x 9.8 inch
Notes

Model JU5 is the AC/DC version of this receiver.

Mentioned in -- Original prospect or advert (Saison 1938-1939)

Model page created by Urmas Tingas. See "Data change" for further contributors.
