0101

0101; CGE - Compagnia (ID = 760289) R-Player 0101; CGE - Compagnia (ID = 760290) R-Player
0101; CGE - Compagnia (ID = 760291) R-Player 0101; CGE - Compagnia (ID = 760293) R-Player
0101; CGE - Compagnia (ID = 767157) R-Player 0101; CGE - Compagnia (ID = 1763349) R-Player
0101; CGE - Compagnia (ID = 1763350) R-Player 0101; CGE - Compagnia (ID = 1763351) R-Player
0101; CGE - Compagnia (ID = 1763352) R-Player 0101; CGE - Compagnia (ID = 1763353) R-Player
Use red slider bar for more.
0101; CGE - Compagnia (ID = 760289) R-Player
CGE - Compagnia: 0101 [R-Player] ID = 760289 670x893
Select picture or schematic to display from thumbnails on the right and click for download.
For model 0101, CGE - Compagnia Generale di Elettricità; Milano

Country:  Italy
Manufacturer / Brand:  CGE - Compagnia Generale di Elettricità; Milano
Year: 1958 Category: Sound/Video Recorder and/or Player
Valves / Tubes 1: ECL82
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: 0101 - CGE - Compagnia Generale di
Material Wooden case
Dimensions (WHD) 350 x 170 x 400 mm / 13.8 x 6.7 x 15.7 inch
Notes Transportable Table Model for main operation only.
Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)

Model page created by Adriano Scarpa. See "Data change" for further contributors.



All listed radios etc. from CGE - Compagnia Generale di Elettricità; Milano
Here you find 297 models, 241 with images and 219 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
