• Country
• Italy

• Manufacturer / Brand
• CGE, Compagnia Generale di Elettricità; Milano

• Year
• 1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 107088

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH3 6K7 6Q7 6L6 EM1 5Y3

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 1343 - CGE, Compagnia Generale di

• Shape
• Console with any shape - in general

• Notes

• Stesso circuito dei modelli 1341 e 1342 ma con variante alla valvola finale.

  Controllo di tono.

• Price in first year of sale
• 3,650.00 LIT

• Source of data
• Guida Pratica Antique Radio II (2000)

• Mentioned in
• -- Schematic (La Riparazione degli Apparecchi Radio Delforno-Colciago - Lavagnolo - Italy - 1941)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.

• Other Models

• Here you find 323 models, 260 with images and 238 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from CGE, Compagnia Generale di Elettricità; Milano
