- Country
- Italy
- Manufacturer / Brand
- CGE, Compagnia Generale di Elettricità; Milano
- Year
- 1949/1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 198123
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220; 275 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Power out
- 10 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 787B - CGE, Compagnia Generale di
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 1050 x 885 x 420 mm / 41.3 x 34.8 x 16.5 inch
- Notes
- 16 gamme d'onda. Radiofonografo. Gamme d'onda: medie, medie-corte, corte, cortissime. Gruppo AF uguale a quello del CGE 185. Variante di mobile del 787A.
- Source of data
- Guida Pratica Antique Radio IV (2001)
- Literature/Schematics (1)
- Schemi di apparecchi radio ( Ravalico 1953 ) (pag. 39)
- Author
- Model page created by Alessandro De Poi. See "Data change" for further contributors.
