Familial 56 Combiné Radio-Phono
Cibot Radio; Paris
- Country
- France
- Manufacturer / Brand
- Cibot Radio; Paris
- Year
- 1956
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 236776
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 4 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Familial 56 Combiné Radio-Phono - Cibot Radio; Paris
- Shape
- Tablemodel with Push Buttons.
- Notes
-
4 gammes d'ondes: OC 18,2 à 5,75 Mc, PO 1610 à 520 Kc, GO 302 à 149 Kc, BE 6,45 à 5,92 Mc. Clavier 5 touches, cadre à air incorporé. HP élliptique de 12 x 19 cm.
Platine Teppaz ou Visseaux 3 vitesses.
- Mentioned in
- - - Manufacturers Literature
- Other Models
-
Here you find 134 models, 121 with images and 53 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Cibot Radio; Paris
