8-Track Cartridge Stereo Player HE-202A(B)

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2520990) R-Player

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2520991) R-Player

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2520989) R-Player

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2518966) R-Player

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2518968) R-Player

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2518969) R-Player

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2518970) R-Player

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2520957) R-Player

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2520960) R-Player

8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2520961) R-Player
8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2521011) R-Player
Use red slider bar for more.
8-Track Cartridge Stereo Player HE-202A; Clarion Co., Ltd.; (ID = 2521011) R-Player
Clarion Co., Ltd.;: 8-Track Cartridge Stereo Player HE-202A [R-Player] ID = 2521011 600x450
Select picture or schematic to display from thumbnails on the right and click for download.
For model 8-Track Cartridge Stereo Player HE-202A(B), Clarion Co., Ltd.; Tokyo:
ebay.de #123086142595 seller noord.de2014

Country:  Japan
Manufacturer / Brand:  Clarion Co., Ltd.; Tokyo
Year: 1975 ?? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 19: 2SC732 or. 2SC458 2SC373 2SC735 or. 2SC984 2SD235 or. 2SC1061 M8513 or. HV23G or. HV46 SH-1 10DC-1
Main principle Audio-Amplification
Wave bands - without
Details Special Tape or Cassette-Format
Power type and voltage Alternating Current supply (AC) / 117 or 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 10 W (unknown quality)
from Radiomuseum.org Model: 8-Track Cartridge Stereo Player HE-202A - Clarion Co., Ltd.; Tokyo
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 14 x 10.2 x 7.9 inch / 356 x 259 x 201 mm
Notes

8-Track Cartridge Stereo Player for home use.

2 channel, 4 program stereo tape player
Wow and flutter: < 0.3 %
Semi-complimentaroy SEPP ITL, OTL circuit
Rated output: 2 x 5W
Frequency response: 20 - 30,000 Hz

Power requirements:
HE-202A: 117 VAC, 60 Hz
HE-202B: 220 VAC, 50 Hz

Optional components:
Speaker kit SKA-030
Headphone HPA-003-000 or HPA-001-000
Microphone DMA-048-000

Semiconductors listed once per type. 19 Transistors, 11 diodes.

Net weight (2.2 lb = 1 kg) 14.4 lb (14 lb 6.4 oz) / 6.538 kg
Mentioned in -- Original-techn. papers.

Model page created by Frans Raes. See "Data change" for further contributors.



All listed radios etc. from Clarion Co., Ltd.; Tokyo
Here you find 90 models, 73 with images and 11 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
