RN 130M

RN 130M; Clarion Co., Ltd.; (ID = 1621041) Car Radio RN 130M; Clarion Co., Ltd.; (ID = 1621042) Car Radio
RN 130M; Clarion Co., Ltd.; (ID = 1621043) Car Radio RN 130M; Clarion Co., Ltd.; (ID = 1621044) Car Radio
Use red slider bar for more.
RN 130M; Clarion Co., Ltd.; (ID = 1621041) Car Radio
Clarion Co., Ltd.;: RN 130M [Car Radio] ID = 1621041 933x479
Select picture or schematic to display from thumbnails on the right and click for download.
For model RN 130M, Clarion Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Clarion Co., Ltd.; Tokyo
Year: 1956 ?? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 7: 2SA353 2SA354 2SA355 2SC458 2SB77 2SB367 2SB367
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: RN 130M - Clarion Co., Ltd.; Tokyo
Material Metal case
Shape Rack
Dimensions (WHD) 180 x 62 x 120 mm / 7.1 x 2.4 x 4.7 inch
Net weight (2.2 lb = 1 kg) 0.840 kg / 1 lb 13.6 oz (1.85 lb)

Model page created by José Manuel Silvestre. See "Data change" for further contributors.



All listed radios etc. from Clarion Co., Ltd.; Tokyo
Here you find 90 models, 73 with images and 11 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
