• Country
• United States of America (USA)

• Manufacturer / Brand
• Clinton Mfg.Co.; Chicago, IL

• Year
• 1935 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 299102

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 78 6C6 37 38

• Main principle
• TRF (Tuned-Radio-Frequency but use of regeneration unknown); 1 AF stage(s)

• Tuned circuits
• 2 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set / 110-120 Volt

• Loudspeaker
• -Loudspeaker incorporated, but system not known. / Ø 10 cm = 3.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: General - Clinton Mfg.Co.; Chicago, IL

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 250 x 200 x 150 mm / 9.8 x 7.9 x 5.9 inch

• Notes

• This radio uses the type 37 triode tube as a rectifier.

  The original speaker type is unknown since the speaker has been replaced in this radio.

• Net weight (2.2 lb = 1 kg)
• 2.5 kg / 5 lb 8.1 oz (5.507 lb)

• Author
• Model page created by Spartaco Gori. See "Data change" for further contributors.

• Other Models

• Here you find 135 models, 81 with images and 47 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Clinton Mfg.Co.; Chicago, IL
