• Year
  • 1964 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 103439
    • Brand: Defiant

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 200-250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • from Radiomuseum.org
  • Model: Defiant T14 - Co-operative Wholesale Society
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Portable tape recorder using BSR type TD2 deck. Single speed (3.75 in/sec), 4 track.
  • Circuit diagram reference
  • Radio and TV Servicing books (R&TVS) book
  • Mentioned in
  • -- Original-techn. papers.
  • Literature/Schematics (1)
  • Trader Sheet 1663
  • Author
  • Model page created by Peter Hoddow. See "Data change" for further contributors.
