• Country
• Spain

• Manufacturer / Brand
• Comercial Radio Bertrán; Electrónica Bertrán; ELBE; Barcelona

• Year
• 1955 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 220102

• Number of Tubes
• 5

• Valves / Tubes
• UCH81 UF80 UBC41 UL84 UY85

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Desconocido Unknown 2 Baquelita, dial alargado, 4 mandos - Comercial Radio Bertrán;

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 290 x 180 x 125 mm / 11.4 x 7.1 x 4.9 inch

• Net weight (2.2 lb = 1 kg)
• 2.5 kg / 5 lb 8.1 oz (5.507 lb)

• Author
• Model page created by Juan Aljaro Estepa. See "Data change" for further contributors.

• Other Models

• Here you find 275 models, 110 with images and 84 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
