ELBE 1212 Ch= P80 (12" y 17")

Comercial Radio Bertrán; Electrónica Bertrán; ELBE; Barcelona

Data
Forum
Pictures
Collections

  • Year
  • 1979
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 278459

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • 9
  • Main principle
  • Superheterodyne (common); ZF/IF 38900 kHz
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / 125; 220 / 12 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: ELBE 1212 Ch= P80 - Comercial Radio Bertrán;
  • Shape
  • Tablemodel, low profile (big size).
  • Notes

  • ELBE 1212 TV B/N de 12" con chasis P-80 para televisores de 12" y 17". Existe una versión de este chasis P-80 para TV de 14" con fuente de alimentación diferente.

    Ni contados ni listados los semiconductores del sintonizador Philips ELC2004

  • Literature/Schematics (1)
  • -- Original-techn. papers. (Boletín ELBE Service 16 y 17 (1979))
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
