ELBE 2430 Ch=7629

Comercial Radio Bertrán; Electrónica Bertrán; ELBE; Barcelona

Data
Forum
Pictures
Collections

  • Year
  • 1978 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 312822

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • 18
  • Main principle
  • Superhet with RF-stage; ZF/IF 38900 kHz
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 100-135; 180-235 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 2.5 W (undistorted)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: ELBE 2430 Ch=7629 - Comercial Radio Bertrán;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 740 x 508 x 370 mm / 29.1 x 20 x 14.6 inch
  • Notes

  • ELBE 2430 TV B/N, TRC de 24"/110º y sintonizador VHF/UHF Philips Miniwatt ELC2000S

    Altavoz elíptico de 4" x 6". Z= 16 Ω

    La parte de sonido puede venir con un único integrado tipo 221-98 (Ch= 7629) o con dos integrados TBA120S + TBA800 (ver Ch= 7729).

    Los 5 primeros transistores y los tres primeros diodos pertenecen al sintonizador.

  • Net weight (2.2 lb = 1 kg)
  • 30 kg / 66 lb 1.3 oz (66.079 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
