RS4B 8961

RS4B 8961; Condal Radio Co., (ID = 789118) Radio

RS4B 8961; Condal Radio Co., (ID = 789119) Radio
RS4B 8961; Condal Radio Co., (ID = 824232) Radio RS4B 8961; Condal Radio Co., (ID = 800344) Radio
RS4B 8961; Condal Radio Co., (ID = 800345) Radio RS4B 8961; Condal Radio Co., (ID = 800348) Radio
Use red slider bar for more.
RS4B 8961; Condal Radio Co., (ID = 824232) Radio
Condal Radio Co.,: RS4B 8961 [Radio] ID = 824232 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model RS4B 8961, Condal Radio Co., Buenos Aires

Country:  Argentina
Manufacturer / Brand:  Condal Radio Co., Buenos Aires
Year: 1940 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: EK2 EF9 6Q7 25A7 EM1
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 14 cm = 5.5 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: RS4B 8961 - Condal Radio Co., Buenos Aires
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 300 x 170 x 160 mm / 11.8 x 6.7 x 6.3 inch
Source of data - - Data from my own collection

Model page created by Heriberto Tavella. See "Data change" for further contributors.



All listed radios etc. from Condal Radio Co., Buenos Aires
Here you find 1 models, 1 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
