Digi-Scope-Converter 500

• Country
• Germany

• Manufacturer / Brand
• Conrad Electronic (Voltcraft), Radio-Conrad, Conrad & Co; Berlin, Hirschau

• Year
• 1985 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 198443

• • Brand: Voltcraft

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 1

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: Digi-Scope-Converter 500 - Conrad Electronic Voltcraft,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 250 x 80 x 165 mm / 9.8 x 3.1 x 6.5 inch

• Notes
• der Converter erweitert das vorhandene Oszilloskop um Spannungs-, Zeit- und Frequenzmessung.
  Bandbreite: 100 kHz.
  Eingangswiderstand: 1 MOhm parallel 40 pF.
  max. Eingangsspannung: +/-250 V

• Net weight (2.2 lb = 1 kg)
• 1.4 kg / 3 lb 1.3 oz (3.084 lb)

• Price in first year of sale
• 598.00 DM

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Wolfgang Feige. See "Data change" for further contributors.
