Pocket Phone

Pocket Phone ; Conrad Electronic (ID = 1780271) Citizen Pocket Phone ; Conrad Electronic (ID = 1780272) Citizen
Pocket Phone ; Conrad Electronic (ID = 1780273) Citizen Pocket Phone ; Conrad Electronic (ID = 1780274) Citizen
Pocket Phone ; Conrad Electronic (ID = 2281004) Citizen Pocket Phone ; Conrad Electronic (ID = 2281005) Citizen
Pocket Phone ; Conrad Electronic (ID = 2281006) Citizen
Use red slider bar for more.
Pocket Phone ; Conrad Electronic (ID = 1780271) Citizen
Conrad Electronic: Pocket Phone [Citizen] ID = 1780271 622x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Pocket Phone, Conrad Electronic (Voltcraft), Radio-Conrad, Conrad & Co; Berlin, Hirschau

Country:  Germany
Manufacturer / Brand:  Conrad Electronic (Voltcraft), Radio-Conrad, Conrad & Co; Berlin, Hirschau
Brand

Voltcraft
Year: 1989 Category: Citizen Band Equipment
Semiconductors (the count is only for transistors) 3: LM386
Main principle Transceiver
Wave bands Short Wave (SW only)
Details
Power type and voltage Dry Batteries / 1 x 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Pocket Phone - Conrad Electronic Voltcraft,
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 55 x 155 x 26 mm / 2.2 x 6.1 x 1 inch
Notes

Conrad Pocket Phone ist ein 1-Kanal CB-Handfunksprechgerät für Frequenzmodulation, für den Nachrichtenaustausch über kurze Distanzen.

  • 1 Kanal bequarzt (19 = 27,185 MHz)
  • Sendeleistung 0,199 W (Hersteller-Angabe)
  • Effektive Strahlungsleistung (ERP) 5 mW
  • Länge Teleskopantenne incl. Gerät ca. 90 cm
  • Modulationsart F3E, Hub 1,9 kHz
  • 2 Geräte im Set als Empfangs- und Sprechgeräte.
  • Reichweite ca. 500 m, je nach Umgebungsbedingungen wesentlich mehr (z.B. 8 km).
  • Eingebautes Kondensatormikrofon
  • Conrad Bestell-Nr. 200077
  • Zulassungsnummer der Deutschen Bundespost Z G400 Z535W mit Zusatz K/p vom
    16.März 1989
Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Mentioned in - - Manufacturers Literature

Model page created by Wolfgang Lill. See "Data change" for further contributors.
