CRC-715
Use red slider bar for more.
Crown Radio Corp.;: CRC-715 [Radio] ID = 653812 859x530
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Asahi Radio Mfg. Co., Ltd | ||||
|---|---|---|---|---|---|
| Year: 1976 ?? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. |
| Main principle | Superheterodyne (common) |
|---|---|
| Wave bands | Broadcast (BC) and FM or UHF. |
| Details | Cassette-Recorder or -Player |
| Power type and voltage | Line / Batteries (any type) / 220 / 4 x 1,5 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm |
| Power out | |
| from Radiomuseum.org | Model: CRC-715 - Crown Radio Corp.; Tokyo |
| Material | Plastics (no bakelite or catalin) |
| Shape | Portable set > 8 inch (also usable without mains) |
| Dimensions (WHD) | 290 x 180 x 75 mm / 11.4 x 7.1 x 3 inch |
| Notes | Made in South-Korea. |
| Net weight (2.2 lb = 1 kg) | 2 kg / 4 lb 6.5 oz (4.405 lb) |
Model page created by Jouko Laukkanen. See "Data change" for further contributors.
