• Country
• Italy

• Manufacturer / Brand
• CTE International S.r.l.; Mancasale Reggio nell'Emilia

• Year
• 1975 ??

• Category
• RF (Radio Frequency-) Amplifier

• Radiomuseum.org ID
• 266304

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 2

• Semiconductors
• BC337 2SC1969 1N4148 1N4007

• Main principle
• Radio Frequency Amplification only

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Powered by external power supply or a main unit. / 12 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Alan CB Booster BS 80 - CTE International S.r.l.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 100 x 80 x 35 mm / 3.9 x 3.1 x 1.4 inch

• Notes

• Da utilizzare con apparecchio CB Alan 80/A.





• Net weight (2.2 lb = 1 kg)
• 0.350 kg / 0 lb 12.3 oz (0.771 lb)

• Author
• Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
