Antenna Preamplifier Modulation Meter HQ35

Antenna Preamplifier Modulation Meter HQ35; CTE international S. (ID = 2027642) Citizen
Antenna Preamplifier Modulation Meter HQ35; CTE international S. (ID = 2027639) Citizen Antenna Preamplifier Modulation Meter HQ35; CTE international S. (ID = 1794756) Citizen
Antenna Preamplifier Modulation Meter HQ35; CTE international S. (ID = 1794755) Citizen Antenna Preamplifier Modulation Meter HQ35; CTE international S. (ID = 2027638) Citizen
Antenna Preamplifier Modulation Meter HQ35; CTE international S. (ID = 2027640) Citizen Antenna Preamplifier Modulation Meter HQ35; CTE international S. (ID = 2027641) Citizen
Use red slider bar for more.
Antenna Preamplifier Modulation Meter HQ35; CTE international S. (ID = 2027639) Citizen
CTE international S.: Antenna Preamplifier Modulation Meter HQ35 [Citizen] ID = 2027639 933x717
Select picture or schematic to display from thumbnails on the right and click for download.
For model Antenna Preamplifier Modulation Meter HQ35, CTE international S.r.l. ; Mancasale

Country:  Italy
Manufacturer / Brand:  CTE international S.r.l. ; Mancasale
Year: 1990 ?? Category: Citizen Band Equipment
Semiconductors (the count is only for transistors) 4: BF244 BF244 BC337 BC337 1N4148 1N4148 1N4148 1N4148 1N4148 1N4148
Main principle Radio Frequency Amplification only; something special ? Please give information (notes)
Wave bands Short Wave (SW only)
Details
Power type and voltage Powered by external power supply or a main unit. / 12 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Antenna Preamplifier Modulation Meter HQ35 - CTE international S.r.l. ;
Material Metal case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 120 x 70 x 130 mm / 4.7 x 2.8 x 5.1 inch
Notes

L'apparecchiatura svolge la duplice funzione di preamplificatore d'antenna, con guadagno regolabile fino a 25dB, e da misuratore di percentuale di modulazione per la gamma dei 27 Mhz (CB = citizen band).

L'alimentazione a 12 V in corrente continua è prevista esternamente mediante cavo bipolare con alimentatore o batteria.





Net weight (2.2 lb = 1 kg) 0.6 kg / 1 lb 5.1 oz (1.322 lb)
Price in first year of sale 49.00 Lire
Literature/Schematics (4) -- Schematic

Model page created by Gianluigi Miazzi. See "Data change" for further contributors.



All listed radios etc. from CTE international S.r.l. ; Mancasale
Here you find 51 models, 50 with images and 11 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
