DBX II Dynamic Range Enhancer 124

DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 2134921) Ampl/Mixer DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 2134918) Ampl/Mixer
DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 2134919) Ampl/Mixer DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 2134920) Ampl/Mixer
DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 2134922) Ampl/Mixer DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 2134923) Ampl/Mixer
DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 2134924) Ampl/Mixer DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 2134925) Ampl/Mixer
DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 887507) Ampl/Mixer
Use red slider bar for more.
DBX II Dynamic Range Enhancer 124; dbx Inc.; Waltham MA (ID = 2134921) Ampl/Mixer
dbx Inc.; Waltham MA: DBX II Dynamic Range Enhancer 124 [Ampl/Mixer] ID = 2134921 1400x702
Select picture or schematic to display from thumbnails on the right and click for download.
For model DBX II Dynamic Range Enhancer 124, dbx Inc.; Waltham (MA)

Country:  United States of America (USA)
Manufacturer / Brand:  dbx Inc.; Waltham (MA)
Year: 1977 ? Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: DBX II Dynamic Range Enhancer 124 - dbx Inc.; Waltham MA
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 280 x 96 x 260 mm / 11 x 3.8 x 10.2 inch
Notes Tape noise reduction system with fixed compression and de-compression ratio (2:1). S/N 110dB; Z-in: 50K; V-in:300mV; Z-out: 0,47K; Freq-range: 30-20000Hz. This apparatus must be inserted between the amplifier and the recorder. Works with any recorder because the compression is linear in contrast to Dolby-NR or Dolby-B where the reproduction level must match the recording level. Can also decode DBX vinyl discs.
Tape and disc S/N ratio of 100dB attainable. A DBX vinyl disc can sound as DDD CD. In contrast with the stereophonic DBX-122, this DBX-124 has 4 channels.
Net weight (2.2 lb = 1 kg) 3.170 kg / 6 lb 15.7 oz (6.982 lb)
Price in first year of sale 24'650.00 Bfr

Model page created by Dirk Bladt. See "Data change" for further contributors.
