Radio-Craft Radiophone D6

Radio-Craft Radiophone D6; DeForest Radio (ID = 895713) Radio Radio-Craft Radiophone D6; DeForest Radio (ID = 2048947) Radio
Radio-Craft Radiophone D6; DeForest Radio (ID = 2048950) Radio Radio-Craft Radiophone D6; DeForest Radio (ID = 2048951) Radio
Radio-Craft Radiophone D6; DeForest Radio (ID = 2048952) Radio Radio-Craft Radiophone D6; DeForest Radio (ID = 895715) Radio
Radio-Craft Radiophone D6; DeForest Radio (ID = 895717) Radio Radio-Craft Radiophone D6; DeForest Radio (ID = 1001466) Radio
Radio-Craft Radiophone D6; DeForest Radio (ID = 2048948) Radio Radio-Craft Radiophone D6; DeForest Radio (ID = 2048949) Radio
Use red slider bar for more.
Radio-Craft Radiophone D6; DeForest Radio (ID = 895713) Radio
DeForest Radio: Radio-Craft Radiophone D6 [Radio] ID = 895713 933x691
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radio-Craft Radiophone D6, DeForest Radio Telephone & Telegraph Co. (De Forest); New York

Country:  United States of America (USA)
Manufacturer / Brand:  DeForest Radio Telephone & Telegraph Co. (De Forest); New York
alternative name

Lee De Forest Mfg.
Year: 1922 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3:
Main principle TRF with regeneration
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Radio-Craft Radiophone D6 - DeForest Radio Telephone &
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Notes

Two dials (primary tuning control knobs)

Price in first year of sale 130.00 $
Collectors' prices
External source of data Ernst Erb
Source of data Radio Collector`s Guide 1921-1932
Mentioned in Collector's Guide to Antique Radios 4. Edition


All listed radios etc. from DeForest Radio Telephone & Telegraph Co. (De Forest); New York
Here you find 138 models, 108 with images and 10 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
