De Forest DeForest: Ritz Ch= 9D1092 [Radio] ID = 1374962 933x1378
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ritz Ch= 9D1092, De Forest (DeForest) Crosley Radio, Consolidated Industries; Toronto:
Scanned from the DeForest Folder 1939/40.

Country:  Canada
Manufacturer / Brand:  De Forest (DeForest) Crosley Radio, Consolidated Industries; Toronto
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6K7M 6J8M 6K7M 84M 6X6 6J5M 41M 41M 2X3 2X3
Main principle Superhet with RF-stage; ZF/IF 456 kHz; 2 AF stage(s)
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out
from Radiomuseum.org Model: Ritz Ch= 9D1092 - De Forest DeForest Crosley
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 26 x 38 x 13.75 inch / 660 x 965 x 349 mm
Notes

The 6X6 is a tuning indicator tube. This set uses a push-pull audio output circuit. This model is electrically identical to the Rogers 14/106.

Price in first year of sale 179.95 $
Circuit diagram reference Radio College of Canada
Mentioned in RCC Rogers-Majestic section, pages 65, 66 & Cross-Reference
Literature/Schematics (3) DeForest Folder 1939/40.

Model page created by Robin Roeckers. See "Data change" for further contributors.
