Compact Disc Player DCD-210

Compact Disc Player DCD-210; Denon Marke / brand (ID = 561267) R-Player Compact Disc Player DCD-210; Denon Marke / brand (ID = 1987971) R-Player
Compact Disc Player DCD-210; Denon Marke / brand (ID = 1987972) R-Player Compact Disc Player DCD-210; Denon Marke / brand (ID = 1987973) R-Player
Compact Disc Player DCD-210; Denon Marke / brand (ID = 1987974) R-Player Compact Disc Player DCD-210; Denon Marke / brand (ID = 1987975) R-Player
Compact Disc Player DCD-210; Denon Marke / brand (ID = 1987976) R-Player Compact Disc Player DCD-210; Denon Marke / brand (ID = 1987977) R-Player
Use red slider bar for more.
Compact Disc Player DCD-210; Denon Marke / brand (ID = 561267) R-Player
Denon Marke / brand: Compact Disc Player DCD-210 [R-Player] ID = 561267 567x158
Select picture or schematic to display from thumbnails on the right and click for download.
For model Compact Disc Player DCD-210, Denon (Marke / brand):
Original prospekt in 1996.

Country:  Japan
Manufacturer / Brand:  Denon (Marke / brand)
Year: 1993 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details CD-Player, -Writer, MD, MOD (audio); Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 220 or 230 or 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Compact Disc Player DCD-210 - Denon Marke / brand
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 434 x 92 x 393 mm / 17.1 x 3.6 x 15.5 inch
Notes

A stereo hi-fi compact disc player in a champagne gold metal case. With 8 times oversampling and automatic recording control system (ARCS), 20 Title Programming, Title Search, Auto Edit Function. Line output RCA sockets and digital output coaxial socket. System connector for connection to the matching DRA-210 AM-FM Stereo Receiver which then enables its use with a remote control (RC-130).

Functions:
Direct search, programmed search, repeat playback (all tracks), automatic search,    manual search, time mode, call, editing, replay, random play, etc.

Display:
Track number, time, program, etc.

Specification
Number of channels:   2
Frequency response:  2 to 20,000Hz
Dynamic range:          98dB
S/N ratio:                  107dB
Harmonic distortion:   0.004% (1kHz)
Separation:               105dB
Output voltage:          2.0V, fixed
Signal format
Sampling frequency:  44.1kHz
Quantization bits:      16 bits linear/channel
Pickup Type:             Objective lens drive type optical pickup
Objective lens driving
  method:                  2-dimensional parallel driving
Light source:             Semiconductor laser
Wavelength:              780nm

Versions/Power Requirements
Europe model   /           AC 220/230V 50 Hz
U.K. model      /            AC 240V 50 Hz
Power consumption:     10W

CD-Player, 8fach Oversampling, automatisches Aufnahme-Kontroll-System (ARCS). 20 Titel-Programmierung, Titelsuchlauf, Auto-Edit-Funktion.
Gehäuseausführung Champagnergold.

Der Frequenzgang wird mit 2 Hz bis 20 kHz angegeben, die Dynamik mit 98db, der Rauschabstand mit 107db und die Kanaltrennung mit 105db.

Der Klirrfaktor beträgt 0,004% (1 kHz). Das Gerät hat 10 W Leistungsaufnahme.

Das Gerät verfügt über einen Koax-Digitalausgang und ist über die Systemfernbedienung RC-130 fernbedienbar.

Der DCD-210 bildet zusammen mit dem AM/FM Receiver DRA-210 und dem Autoreserve-Cassettendeck DR-210 eine Gerätelinie, die über die Fernbedienung RC-130 komplett fernbedient werden kann.

Net weight (2.2 lb = 1 kg) 4.3 kg / 9 lb 7.5 oz (9.471 lb)
Source of data -- Original prospect or advert
Literature/Schematics (1) - - Manufacturers Literature (DCD-210 Operating Instructions manual)

Model page created by Franz Scharner. See "Data change" for further contributors.
