- Country
- Germany
- Manufacturer / Brand
- Deutsche Radiophon AG (Haas & Schmidt), Berlin-Cöpenick
- Year
- 1924/1925
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 14171
-
- Brand: Radiophon
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- A_Telefunken
- Main principle
- TRF without regeneration
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage and/or dry batteries / 4 & 90 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Wooden case, TUBES VISIBLE.
- from Radiomuseum.org
- Model: E26 - Deutsche Radiophon AG Haas &
- Shape
- Tablemodel, slant panel.
- Dimensions (WHD)
- 160 x 130 x 110 mm / 6.3 x 5.1 x 4.3 inch
- Notes
- zwangsläufige Rückkopplung.
- Net weight (2.2 lb = 1 kg)
- 0.7 kg / 1 lb 8.7 oz (1.542 lb)
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Circuit diagram reference
- Info Dr. H. Börner without schematic
- Mentioned in
- Funkgeschichte der GFGF (9073)
