• Country
• Spain

• Manufacturer / Brand
• de Wald; Barcelona

• Year
• 1955 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 301158

• Number of Tubes
• 4

• Valves / Tubes
• UCH42 UAF42 UAF42 UL41

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 8 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set / 125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm

• Power out
• 2 W (max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Chavalín - de Wald; Barcelona

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 195 x 120 x 100 mm / 7.7 x 4.7 x 3.9 inch

• Notes

• Comercializado en la decada de 1950-60, como KIT.

• Net weight (2.2 lb = 1 kg)
• 1.270 kg / 2 lb 12.8 oz (2.797 lb)

• Mentioned in
• Radio Historia y Técnica, J.J.E.

• Author
• Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
